Product Details

If you've ever tried moving a tall excavator on a normal trailer, you already know the issue - too high, not stable, and sometimes not even legal on the road. That's where this 3 Axle Lowboy Trailers setup comes in. It's mainly used when height and weight both become a problem.
In real jobs, the lower deck makes a big difference. Machines sit closer to the ground, so the whole load feels more balanced. The frame is made from thick steel, and after long-distance runs, it doesn't easily twist or bend. With three axles underneath, the weight spreads out better, which helps when carrying 40–60 tons.
Loading is also more straightforward. With ramps (hydraulic or mechanical), equipment can drive up slowly without much adjustment. This 3 Axle Lowboy Trailers type is commonly used on construction sites where road conditions are not perfect.
One thing to keep in mind - because of the low structure, ground clearance is limited, so extra care is needed on very uneven roads.

Product Parameters

Parameter	Specification
Model Type	3 Axle Lowboy Trailer
Overall Length	13,000 mm (Customizable)
Overall Width	2,550 mm / 3,000 mm
Loading Deck Height	1,000 - 1,200 mm (Low Profile)
Rated Load Capacity	40T - 60T
Number of Axles	3 Axles (Heavy-Duty)
Axle Configuration	13T/16T Heavy-Duty Axles (BPW/FUWA Option)
Suspension Type	Heavy-Duty Mechanical Leaf Spring Suspension
Tire Specification	12R22.5 or 315/70R22.5 Radial Tires
Main Beam Material	High-Tensile Q345B / Q690D Steel
Gooseneck Design	Integral Gooseneck for Low Center of Gravity
Kingpin	2" or 3.5" (Heavy-Duty Forging)
Brake System	Air Brake System with ABS
Rear Ramp	Hydraulic or Mechanical Assist (Optional)

Product Features

Three-Axle Setup
The weight is shared across three axles, which helps keep the trailer stable during transport. It also reduces pressure on any single point.

Strong Frame
The main beam uses high-strength steel. Under heavy load, it stays firm and doesn't show obvious deformation after repeated use.

Low Deck Height
The lower platform helps carry taller equipment without pushing height limits too far. This can make transport planning easier in some regions.

Loading Convenience
With optional ramps, machines can be driven on and off without complicated handling. The angle is manageable for most construction equipment.

Flexible Options
Length, axle capacity, and side structures can be adjusted. This 3 Axle Lowboy Trailers design works for different types of heavy cargo, not just machinery.

Our main products

Besides this model, we also supply tractor trucks, dump trucks, fuel tankers, and water trucks.
Our semi-trailer range includes flatbeds, container chassis, skeleton trailers, side wall trailers, van trailers, cement tank trailers, and car carriers. If your work needs something specific, we can adjust the configuration based on your requirements.

product-1200-1000

After Sales Service

Before shipping, each vehicle is checked step by step. The engine is tested for smooth start, gearbox shifting is checked, and axles are inspected for sealing.
The frame is also reviewed to make sure there are no structural issues. Lights and wipers are tested as well. A basic inspection report can be provided so you know what has been checked.

Packing & Delivery

Shipping depends on order size and destination. Usually, we arrange bulk vessel, RORO, or container transport.
Before loading, the trailer is coated with wax to reduce rust during sea transport. It is fixed securely to avoid movement, and some protective materials are added to reduce scratches.

product-1200-880
